PLEASE NOTE THAT THE USB SLOT COVER IS MISSING – DOES NOT AFFECT USE

The TRIGGER CAM 2.1 mobile app provides the user with a fully integrated control interface to your Triggercam through Wi-Fi
connectivity.

The app is available on both IOS & Android platforms, downloadable from the app stores free.

The app for TRIGGER CAM 2.1 provides users with the following interactive functions:

• Livestream Triggercam to your mobile device.

• Control the recording of your Triggercam from your device.

• Record, save and view videos directly from your device.

• Share your video/photo content on Social media platforms and with friends.

• Access the gallery of all your video/photo content on your mobile device.

TRIGGER CAM 2.1 Specifications

• Aircraft grade aluminum and proprietary anti shock materials: Military grade design, engineered to withstand recoil force
and unforgiving outdoor conditions
• Dimensions –  L 100mm x W 50mm x H 93.2mm
• Weight – 453 grams
• Rifle Scope Eyepiece compatibility – 32mm – 48mm
• Smart Phone APP – Triggercam 2.1 App available on Android, IOS & Huawei operating systems.
Live streaming capability, video gallery, camera control, download and edit videos.
• Memory – SD Card up to 128G, Class U3 or Above.
• Wi-Fi – Integrated Wi-Fi with live streaming function and instant downloading of videos
• Quick record –  Switches on power and record function for instant recording
• Optics – Multi coated optical lens for optimal performance.
• Video stabilization –  Advanced video stabilization technology assists in optimal quality videos minimizing recoil effects.
• Function can be switched ON/OFF
• Waterproof –  IP64 rating
• Battery –  Integrated lithium ion battery with 2.5 hours recording time, and 10 hours standby time
• High definition slow motion video replay –  4 x (1080P 100/120fps) / 8 x (720P 200/240fps)
• True sound microphone –  Able to record high quality sound 360 degree true sound, able to switch on and off
• Resolution – 4K 30fps
• 1080P 120fps/60fps/30fps
• 720P 240fps/120fps
• USB –  C-type USB,
• HDMI –  Micro HDMI for TV output
• Video output –  PAL/NTSC
• Recording Timing Alarm –  Off/3min/5min/10min
• Input Voltage – 5V
• Other features – Auto low light function
