The Pixfra Mile M40 13mm Thermal Monocular is part of the Pixfra Mile Series, and is a thermal imaging monocular that provides excellent thermal imaging capabilities at long range thanks to a sensitive thermal sensor and a powerful objective lens.

It features a wide range of intuitive functionalities, including stadiametric range finding capabilities, hot spot tracking, long-life battery, built-in Wi-Fi, and more.

Designed to increase situational awareness both by day and after dark, the Mile M40-B13 can detect human, and animal heat sources with ease, allowing users to stay aware of activity within their observation area.

Pixfra’s advanced image processing algorithms work to present a much more vivid thermal picture, ensuring the image displayed on the device’s 1280×960 viewfinder is always crisp and well-defined, providing the user with good identification capabilities.

The Mile M40-B13 features adjustable dioptre control, ensuring an image that always remains crystal-clear when viewed through the viewfinder. This control allows the device to be set to match the eyesight of different users, providing a more comfortable, fatigue-free viewing experience.

A built-in stadiametric rangefinder allows the user to gauge distance measurements between themselves and an observed object. Marking the top and bottom of the observed object will allow the Mile M40-B13 to automatically ascertain the distance between object and user, allowing them to make well-informed decisions out in the field.

Capturing every moment during observation is made possible through the Mile M40-B13’s built-in still image and video recording capabilities. Videos and pictures can be stored on a MicroSD card with a capacity of up to 256GB.

A built-in Wi-Fi module allows this device to connect to the Pixfra App (see the APP tab above), meaning users can view what’s observed through the M40-B13’s lens directly on their connected smartphone. What’s more, this device allows for multiple phones to be connected simultaneously, allowing for group observation over several smart devices.

A built-on laser pointer is included in order to allow the user to pinpoint specific objects to team members when out in the field. To protect the eyes, the laser pointer automatically disables after 10 seconds of use.

Although this device is exceptionally lightweight at less than 350g, it is more than capable of withstanding harsh environmental conditions thanks to its IP67 rating. This rating protects the monocular from dust and water ingress, and a 2m drop test also ensures that the Mile M40-B13 is more than durable enough to resist any bumps or knocks that may occur during observation or transportation.

This monocular will even work unaffected in extreme temperature, providing excellent thermal imaging capabilities in -20℃ – +50℃.

Pixfra Mile M40 13mm Thermal Monocular Features:

• Fire Detection, 1000m
• Cold/Hot Spot Trace
• Proximity Sensor
• Distance Measurement
• Long Battery Life
• Wifi Hotspot and App
• Smart Standby Mode
• Compat Structure Design

Pixfra Mile M40 13mm Thermal Monocular Specifications:

• Detector – Uncooled Vox focal plane array
• Effective Pixels – 400 x 300
• Pixel Pitch – 17µm
• Focal Length – 13mm
• Magnification – 0.86x
• Field of View – 24.0° x 2.6°
• Detection Ranges – 508m / 1666.67ft
• Sensitivity (NETD) – ≤35 mK@f/1.0
• Screen Resolution – 1280 x 960
• Colour Modes – 5 (white hot, black hot, rainbow, iron red, alarm)
• Close Focus Distance – 3m / 9.84ft
• USB Port – Micro USB
• Power Supply Mode – 5 VDC, 0.3A or built-in battery powered
• Battery Life – >5h

Model: M40-B13
Product Code: PIX-DHI-TPC-M40-B13-G
