Pard DS35 50RF Specifications

  • Resolution(px) – 2560×1440
  • Pixel size(um) – 2.9µm
  • Sensitivity(lux) – 0.001lx
  • Frame rate(fps) – Colour 60fps
    B&W 30fps
  • Image engine – PARD VLEA
  • Objective lens – 50mm F2.4
  • Optical magnification(x) – 4x
  • Digital zoom(x) – 2x
  • Field of view (HxV) Horizontal – 4.8
  • Field of view (HxV) Vertical – 4.8
  • Field of view (HxV) Diagonal – 6.8
  • Eye relief(mm) – 100
  • Exit pupil(mm) – 10
  • IR type – LED
  • IR power(W) – 5W
  • IR illuminating level – 3 levels
  • IR distance(m) – 350m
  • IR wavelength(nm) – 850
  • Type – IPS LCD
  • Resol ution(px) – 800x800px
  • Reticle style – 6
  • Reticle color – white/yellow/green
  • Color mode – Color/Mono BW/Mono Green/Mono Yellow
  • Photo resolution(px) – 2560×1440
  • Photo format – JPG
  • Video resolution(px) – 1920×1080
  • Video formatMP4
  • Storage – TF Card (128GB)
  • Battery type – Lithium Ion18650*1
  • Output voltage(V) – 3.7V
  • Operating time(h,max) – 8hrs Max
  • External power supply(V) – USB-C
